Silent Sentinel Thermal Imager Plus HD PTZ Camera

Oculus TI.fw

Silent Sentinel Thermal
Imager Plus HD PTZ Camera

Rugged pan/tilt unit with dual HD video and thermal modules

SDI or IP Available
The Silent Sentinel Thermal Imager Plus HD PTZ Camera is the perfect solution for mid-range surveillance applications, providing the best performance available within a rugged pan and tilt casing of this size.

DRS’ proven un-cooled 320 x 240 or 640 x 480, 17μm VOx thermal imaging technologies is employed to provide man detection up to 2.1 kilometres. The thermal uses ICE to enhance contrast and features continuous digital zoom. All models also offer simultaneous video verification provided by a 30x HD zoom module.

As with all Oculus units, everything is fully housed within a hard anodised aluminium casing, fully rated to IP67 and ready to handle the harshest environments. The toughened, optically flat glass provides clear images, even at the highest zoom levels and can be kept clean at all times by the compact wiper unit. Optical encoders for both the pan and tilt axes provide highly accurate positioning and repeatability, allied with self-correction systems that will counteract any external interference with the moving head.

Silent Sentinel Thermal Imager Plus Specifications

Feature Specification
Sensor type Uncooled VOx Microbolometer
Pixel size 17μ
Spectral band 8-14μm
Thermal sensitivity
Array format 320 x 240 or 640 x 480
Frames rates 9Hz, 30Hz
Image control White hot, Black hot, Invert
Focus Fixed, preset, Athermalised
Zoom E-zoom 1-4, Region of interest
FOV 19mm (other FOV available)

Silent Sentinel HD PTZ Camera Specifications

Camera Manufacturer Silent Sentinel - Oculus HD
Lens 4.3mm to 129.0mm
Image Sensor 1/2.8” type Exmor
CMOS sensor
Resolution 2.13MP
Optical Zoom / Digital Zoom 30x / 12x
Low Light Color 0.01 lux
Mono 0.0008 lux
Pan & Tilt 360° pan / +90° to -30° tilt
Ingress Protection IP67 waterproof
Communications Pelco-D, Pelco-P, CBC OCP485, Forward Vision Mic1 FV300, Philips, Vicon
Signal System HD: 1080p NTSC/PAL
Camera Warranty 2 years
